| Brand Name : | HTX |
| Model Number : | HTX-P-01 |
| Certification : | POSI CERTIFICATE |
| Price : | 40000-200000/USD |
| Payment Terms : | L/C, D/A, D/P, T/T, MoneyGram, Western Union |
| Supply Ability : | 20Sets/Month |
| Delivery Time : | 30Days |
A concrete sleeper wall machine, also known as a concrete retaining wall machine or concrete block machine, is a piece of equipment used for manufacturing concrete sleepers or blocks that are used in the construction of walls, particularly retaining walls. These machines are designed to produce large quantities of concrete sleepers efficiently and accurately.
Here's a general overview of how a concrete sleeper wall machine works:
Raw Materials: The machine requires cement, aggregates (such as
sand and gravel), water, and sometimes additives depending on the
specific requirements of the concrete mix.
Mixing: The raw materials are combined in precise proportions in a
mixing chamber or mixer. The mixer ensures that the materials are
thoroughly mixed, forming a homogeneous concrete mixture.
Molding: The concrete mixture is then poured into molds or forms
that are designed to create the desired shape and size of the
concrete sleepers. The molds can be customized to produce different
types of sleepers with varying dimensions and surface textures.
Compaction: Once the molds are filled, the machine applies pressure
to compact the concrete mixture and remove any air voids. This
helps in achieving a strong and durable final product.
Curing: After compaction, the concrete sleepers remain in the molds
for a certain period to allow for curing. Curing is the process of
maintaining favorable moisture and temperature conditions that
promote the proper hardening and strength development of the
concrete.
Demolding: Once the curing period is complete, the molds are
opened, and the solidified concrete sleepers are removed from the
machine. They are then stacked or palletized for further handling
and transportation.
It's important to note that the specific design and functionality
of concrete sleeper wall machines may vary depending on the
manufacturer and the desired output. Some machines may have
automated features for improved efficiency, such as automated mold
filling, compaction, and demolding processes.
Specification:
| Name | Model | Specification | Size(mm) | Power(Kw) | Capacity(m2/day) | Weight(Kg) |
| Wet Cast Machinery | HTX-P-01 | Hydraulic driving;Auto feeding; vibrating and timing feeding | 7000*1000*1800 | 12.7 | 1000-1500 | 2000 |
| Wet Cast Machinery | HTX-P-02 | Chain drived;Auto feeding,auto vibration | 8000*1100*1600 | 4.05 | 800-1000 | 1500 |
Applications
Wet cast machinery, is suitable for different silicone molds,
rubber molds and plastic molds, size range from 200*200mm to
1500*1500mm, available for producing the artificial stone both for
paving tile molds, 3D wall molds, wall panel molds, roadside stone
molds, retaining wall molds, wall cap molds, etc.
Support and Services
Wet Cast Machinery technical support and services include:
|
|
