    Automatic Exterior Cultured Stone Making Machine Concrete Cement

    Ask Lasest Price
    Brand Name : HTX
    Model Number :
    Price : 40000-200000/USD
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 500Sets/Month
    Delivery Time : 30days
    Certification : HTX-P-01
    • Product Details
    • Company Profile

    Automatic Exterior Cultured Stone Making Machine Concrete Cement

    Automatic Concrete Cement Exterior Cultured Stone Making Machine For Sale


    Product Description

    wet cast doser dosing machine line equipment for customers to save labor costs, reduce labor, and achieve automation and high-efficiency production. According to the driving method, it can be motor-driven, pneumatic, or hydraulically-driven, pneumatic and electric. According to the size of the concrete mold, they design the length and width of the production line, and also the size and quantity of the mold position. According to the concrete mold size, weight, and customer's production requirements, they design the feeding part, which can be two blanking ports, four blanking ports, or 5 blanking ports, to meet the production quantities of customers with various sizes of products.

    Wet concrete dosing system, is suitable for different silicone molds, rubber molds and plastic molds, size range from 200*200mm to 1500*1500mm, available for producing the artificial stone both for wall and floor paving, 3D Wall panel, terrazzo floor tile, etc .
    The cultural stone production line relates to the technical field of artificial stone production, and discloses an artificial cultural stone mold turning device, comprising a first conveying platform and a second conveying platform arranged in parallel, and a turning frame is arranged between the first conveying platform and the second conveying platform, A clamping mechanism is arranged in the overturning frame, the end of the overturning frame is provided with a holding mechanism corresponding to the clamping mechanism, and the second conveying platform includes a material receiving and conveying mechanism corresponding to the overturning frame and the clamping mechanism.
    The mold is turned over from one conveying platform to another conveying platform through the turning frame, so as to realize the turning of the mold and prepare for the subsequent demoulding. The structure is simple, the turning efficiency is high, and it can be effectively combined with the subsequent demoulding process. , greatly improving the production efficiency, strong practicability and good use effect.

    NameModelSpecification

    Size

    (mm)

    Power

    (Kw)

    Capacity

    (m2/day)

    Weight

    (Kg)

    Artificial stone production lineHTX-P-01

    Hydraulic driving;Auto feeding;

    vibrating and timing feeding

    7000*1000*180012.71000-12002000
    Artificial stone production lineHTX-P-01AFull Auto,timing feeding and vibration, weighing system;12000*1000*20009.1800-10002000

    Automatic Exterior Cultured Stone Making Machine Concrete Cement

    Automatic Exterior Cultured Stone Making Machine Concrete CementAutomatic Exterior Cultured Stone Making Machine Concrete Cement


    Related Products


    FAQ

    1) Q: Are you a factory or a trading company?
    A: We are a foreign trade company integrating factories and trade. We have our own factories and overseas warehouses.
    2) Q: What are the payment terms?
    A: L/C, T/T, Western Union,RMB Cash.
    3) Q: Do you offer formula solutions? A: Yes,we can offer professional making solutions.You can make the color suitable for the floor tiles according to the proportion, and the color and gloss of the made tiles are better.
