    Automatic Artificial Veneer Stone Production Line 2000KG

    Ask Lasest Price
    Brand Name : HTX
    Model Number :
    Price : 40000-200000/USD
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 500Sets/Month
    Delivery Time : 30days
    Certification : HTX-P-01
    • Product Details
    • Company Profile

    Automatic Artificial Veneer Stone Production Line 2000KG

    Automatic Artificial Stone Producing Line Manufactured Stone Veneer Production Line Machine


    Product Description

    Automatic wet concrete cast dosing machine, is suitable for different silicone molds, rubber molds and plastic molds, size range from 200*200mm to 1500*1500mm, available for producing the artificial stone both for wall and floor paving, 3D Wall panel, terrazzo floor tile, etc .The mold is turned over from one conveying platform to another conveying platform through the turning frame, so as to realize the turning of the mold and prepare for the subsequent demoulding. Wet concrete dosing system, is suitable for different silicone molds, rubber molds and plastic molds.
    The cultural stone production line relates to the technical field of artificial stone production, and discloses an artificial cultural stone mold turning device, comprising a first conveying platform and a second conveying platform arranged in parallel, and a turning frame is arranged between the first conveying platform and the second conveying platform,A clamping mechanism is arranged in the overturning frame, the end of the overturning frame is provided with a holding mechanism corresponding to the clamping mechanism, and the second conveying platform includes a material receiving and conveying mechanism corresponding to the overturning frame and the clamping mechanism. Five or Five doser system, with both weight and time control and five dosing switching door with pneumatic system. Each dosing screw can be controlled separately ,and each dosing hopper has its own weighing system, all can be setted up according to the real requirements.Manual cleaning spraying system included.


    Specification

    NameModelSpecification

    Size

    (mm)

    Power

    (Kw)

    Capacity

    (m2/day)

    Weight

    (Kg)

    Artificial stone production lineHTX-P-01

    Hydraulic driving;Auto feeding;

    vibrating and timing feeding

    7000*1000*180012.71000-12002000
    Artificial stone production lineHTX-P-01AFull Auto,timing feeding and vibration, weighing system;12000*1000*20009.1800-10002000

    Automatic Artificial Veneer Stone Production Line 2000KG

    Automatic Artificial Veneer Stone Production Line 2000KG

    Automatic Artificial Veneer Stone Production Line 2000KGAutomatic Artificial Veneer Stone Production Line 2000KG

    Application

    Automatic Artificial Veneer Stone Production Line 2000KGAutomatic Artificial Veneer Stone Production Line 2000KG



    FAQ

    1) Q:Are you a factory or trading company?

    A:We are a trading company integrating factories, overseas warehouses and trade.


    2) Q:Where is your factory located? How can I visit there?

    A:Our factory is located in Zhengzhou, Henan Province, China

    you can fly to Zhengzhou Xinzheng International Airport .

    All our clients, from home or abroad, are warmly welcome to visit us!


    3) Q:What is thepayment terms?

    A: L/C ,T/T, Western Union,Cash


    4) Q:How can I get some samples?

    A: Kindly send us your address, we are honored to offer you samples.
